Shelly

Shelly Wave Pro 3 LR. Z-Wave Long Range 3-Channel Smart Relay

Shelly Wave Pro 3 LR. Z-Wave Long Range 3-Channel Smart Relay

Wave Pro 3 LR US

Ask for Dealer Price
$109.99 USD
$109.99 USD $109.99 USD
Sale Sold out
Shipping calculated at checkout.
Retail: Get Free Shipping using code FREESHIP at checkout on orders from USD 100 (for US Continental, exclusions applies*).
Shipping to Canada or International? Take advantage of new flat rates.
(*)See terms & conditions

Need more quantity? We have it! Contact us and we will get it for you
100% Secure Payments

Shelly Wave Pro 3 Z-Wave Long Range is a 3-channel relay with dry contacts, supporting up to 48 A for professional lighting and appliance automation in residential or commercial applications. Thanks to its Z-Wave Long Range technology, it offers extended wireless coverage and reliable performance across larger buildings and complex installations. Equipped with potential-free outputs, it provides high flexibility in voltage compatibility and versatile applications. Easily set different types of actions, scenarios, and schedules to align with your daily routines or business needs.

5 Years Manufacturer Warranty

Key Features Shelly Wave Pro 3 LR

  • 3 outputs, 16 A each. Total device maximum of 48 A
  • DIN-rail mountable
  • Dry contacts
  • Extremely low power consumption: < 0.3 W
  • Z-Wave Long Range frequency band: 912 MHz
  • Latest technology: Z-Wave 800 Series
  • Automatic set-up with SmartStart
  • Security 2 Authenticated for the highest level of security
  • Over-the-air firmware updates
  • Works with Z-Wave-certified gateways and over 4,000 Z-Wave devices
View full details

Use Cases

  • Lights

    Control and automate professional or residential lighting across multiple zones with independent schedules and smart scenarios.

  • Appliances

    Remotely manage and schedule high-consumption appliances to reduce energy waste and optimize power use.

  • Valves

    Integrate with motorized valves to intelligently manage heating, cooling, or water distribution systems with precise control.

  • Heating & Cooling

    Automate HVAC systems for efficient temperature management in guest rooms, offices, or commercial spaces, improving comfort while saving energy.

  • Office Energy Management

    Use the relay to cut power to non-essential office equipment after hours and on weekends, reducing consumption and lowering monthly energy costs.

Functionalities

  • Z-Wave operated

    Connect the device to your Z-Wave network and control it remotely.

  • Dry contacts

    Supporting low and high voltages, this device enables you to control a wide range of AC devices and appliances.

  • Custom schedules

    Create personalized schedules aligned with your daily routine or synchronize with sunrise/sunset to manage your lighting (gateway required).

  • Z-Wave Long Range

    The range of the device is exceeding 1 mile (line of sight). ZWLR works as a star network.

  • Smart scenes

    Set custom scenes by combining the device with any other Z-Wave devices (gateway required).

  • DIN-mountable

    Intended to be installed inside the breaker box and designed to meet the global DIN rail standardization.

Shelly Wave works on Z-Wave

By using Z-Wave, smart home products can seamlessly communicate with each other, regardless of their brand or platform, thanks to a centralized smart hub! Shelly devices work on the latest Z-Wave chip generation (S800), one of the most popular standardized technologies for smart homes in the world.
Shelly Wave devices work with over 4000 Z-Wave certified devices and gateways

*Z-Wave devices have specific requirements in order to function correctly, such as the necessity to use a supported Z-Wave hub. For more information, please visit the official Z-Wave website: www. z-wavealliance.org

Z-wave features

  • Security z-wave

    Bulletproof security

    Security 2 (AES128 encryption) for the utmost safety of your Z-Wave network

  • ultra low power consumption

    Ultra-low power consumption

    Most of the Wave devices operate at less than 0.3W

  • high compatibility

    High compatibility

    Compatible with all certified Z-Wave devices and gateways available in the market

  • Extended wireless Long Range

    Up to 80 m indoor range. Device acts as a Z-Wave signal repeater, extending
    the Z-Wave network range

  • wifi icon

    High reliability

    Operates on a sub-GHz frequency, ensuring stable and reliable wireless connection without interference

  • Set up icon

    Automatic set-up

    SmartStart for automatic inclusion to your Z-Wave network

Universally compatible

You can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system.

 Shelly App
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms

Universally compatible

You can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system.
Shelly App
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Technical Specifications
Power supply AC 110-240V ±10%, 50/60Hz
Power supply DC No
Maximum load 16 A per channel, 48 A total
Power measurement Yes
Dry contacts No
Channels 3
Operational temperature 0°C to +40°C
Device power consumption Up to 1.5 W
Radio protocol Z-Wave
Radio frequency 908.4 MHz (US); 912 MHz (Z-Wave LR)
Range Up to 40m indoors / 50m outdoors (depending on local conditions)
Dimensions 90 x 52 x 57 mm

Warranty

  • USA Pro Market Manufacturer Warranty: Lifetime manufacturer warranty (only if installed by a professional within USA) when purchased at Digital Bay Tech.

  • Retail Standard Manufacturer Warranty (included in purchase price): 2, 3 or 5 years manufacturer warranty covers only the hardware (corpus, mechanics, and display, if any) and does not cover consumables (battery) and accessories insofar as these are subject to exhaustion (decrease of their useful life) depending on the intensity of their use. Device malfunctions are only covered when device is used as described conditions within user manual (max loads, proper installation, etc.). Please check refund policy for further details.
  • Gen 1: 2 years.
  • Plus, Gen 3, Wave: 3 years.
  • Pro Line: 5 years.

Special Notes

  • Do It Yourself: Devices are technically user-installable in many locales, nevertheless consulting a licensed electrician to install shelly components is recommended; in addition to being licensed to work with electrical devices, they are also familiar with local building codes and regulations to keep your safety.
  • Manufacturer's Safety note: Each Shelly device generates heat under load. Do not combine two or more Shelly devices stacked on top of or beside each other in a confined space. There must be a minimum distance of 0.4 inch / 1 cm between them to allow for airflow.
