Shelly Wave 1PM Mini LR US. Smart Energy Monitoring Relay with Z-Wave Long Range

Shelly Wave 1PM Mini LR US. Smart Energy Monitoring Relay with Z-Wave Long Range

Wave 1PM Mini LR US

Ask for Dealer Price
$29.99 USD
$29.99 USD $29.99 USD
Sale Sold out
Shipping calculated at checkout.
Retail: Get Free Shipping using code FREESHIP at checkout on orders from USD 100 (for US Continental, exclusions applies*).
Shipping to Canada or International? Take advantage of new flat rates.
(*)See terms & conditions

Need more quantity? We have it! Contact us and we will get it for you
100% Secure Payments

The ideal retrofit solution for lights, appliances, and fans—offering precise energy monitoring and now supporting Z-Wave Long Range for extended connectivity.

A gateway (smart hub) is not included. A gateway (smart hub) is required for the configuration of the device.

3 Years Manufacturer Warranty

Key Features Shelly Wave 1PM Mini LR

  • Supports up to 8 A at 240 V AC
  • Power measurement
  • Z-Wave frequency: 912 MHz (ZWLR) & 908.4 MHz (Z-Wave Plus)
  • Energy efficient: uses only up to 0.3 W of power
  • Latest technology: Z-Wave 800 Series
  • Easy set up with SmartStart - just scan and go
  • Security 2 Authenticated for the highest level of security
  • Supports over-the-air firmware updates
  • Simple installation in most standard electrical boxes and switches

*A gateway (smart hub) is not included. A gateway (smart hub) is required for the configuration of the device.

View full details

Use Cases

  • Lights

    Easily control and monitor the power consumption of ceiling lights, wall lights, or LED fixtures, ensuring energy savings and reliable on/off automation.

  • Appliances

    Automate and measure energy usage for small household appliances such as coffee makers, toasters, or air purifiers, helping you optimize electricity costs.

  • Fans

    Switch and monitor exhaust fans, ceiling fans, or bathroom ventilation fans with ease, adding smart scheduling and remote control through your Z-Wave hub.

  • Power Measurement

    Track real-time energy consumption on any connected circuit up to 8 A, providing valuable insights into your household or office energy usage.

  • Transform existing outlets into smart-controlled sockets for devices under 8 A, adding both switching capability and energy metering while keeping installation simple.

    Sockets and Outlets

Functionalities

  • Z-Wave operated

    Include the device to your Z-Wave network and control it remotely.

  • Custom schedules

    Set custom schedules based on your daily agenda or automatically follow the sunrise/sunset and control your appliances accordingly (gateway required)

  • Smart Scenes

    Set custom scenes by combining the device with your other Shelly Wave devices (gateway required).

  • Power monitoring

    The device provides precise power consumption monitoring.

  • Z-Wave Long Range

    The range of the device is exceeding 1 mile (line of sight). ZWLR works as a star network.

  • Wide range of voltage support

    Use a wide range of output voltage levels. Supports low voltages.

Shelly Wave works on Z-Wave

By using Z-Wave, smart home products can seamlessly communicate with each other, regardless of their brand or platform, thanks to a centralized smart hub! Shelly devices work on the latest Z-Wave chip generation (S800), one of the most popular standardized technologies for smart homes in the world.
Shelly Wave devices work with over 4000 Z-Wave certified devices and gateways

*Z-Wave devices have specific requirements in order to function correctly, such as the necessity to use a supported Z-Wave hub. For more information, please visit the official Z-Wave website: www. z-wavealliance.org

Z-wave features

  • Security z-wave

    Bulletproof security

    Security 2 (AES128 encryption) for the utmost safety of your Z-Wave network

  • ultra low power consumption

    Ultra-low power consumption

    Most of the Wave devices operate at less than 0.3W

  • high compatibility

    High compatibility

    Compatible with all certified Z-Wave devices and gateways available in the market

  • Extended wireless Long Range

    Up to 80 m indoor range. Device acts as a Z-Wave signal repeater, extending
    the Z-Wave network range

  • wifi icon

    High reliability

    Operates on a sub-GHz frequency, ensuring stable and reliable wireless connection without interference

  • Set up icon

    Automatic set-up

    SmartStart for automatic inclusion to your Z-Wave network

Universally compatible

You can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system.

 Shelly App
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms

Universally compatible

You can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system.
Shelly App
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Technical Specifications
Power supply AC 110-240V ±10%, 50/60Hz
Power supply DC No
Maximum load 16 A
Power measurement Yes
Dry contacts No
Operational temperature 0°C to +40°C
Device power consumption Up to 0.3 W
Radio protocol Z-Wave
Radio frequency 908.4 MHz (US); 912 MHz (Z-Wave LR)
Range Up to 40m indoors / 50m outdoors (depending on local conditions)
Dimensions 38 x 33 x 15 mm

Warranty

  • USA Pro Market Manufacturer Warranty: Lifetime manufacturer warranty (only if installed by a professional within USA) when purchased at Digital Bay Tech.

  • Retail Standard Manufacturer Warranty (included in purchase price): 2, 3 or 5 years manufacturer warranty covers only the hardware (corpus, mechanics, and display, if any) and does not cover consumables (battery) and accessories insofar as these are subject to exhaustion (decrease of their useful life) depending on the intensity of their use. Device malfunctions are only covered when device is used as described conditions within user manual (max loads, proper installation, etc.). Please check refund policy for further details.
  • Gen 1: 2 years.
  • Plus, Gen 3, Wave: 3 years.
  • Pro Line: 5 years.

Special Notes

  • Do It Yourself: Devices are technically user-installable in many locales, nevertheless consulting a licensed electrician to install shelly components is recommended; in addition to being licensed to work with electrical devices, they are also familiar with local building codes and regulations to keep your safety.
  • Manufacturer's Safety note: Each Shelly device generates heat under load. Do not combine two or more Shelly devices stacked on top of or beside each other in a confined space. There must be a minimum distance of 0.4 inch / 1 cm between them to allow for airflow.
