Shelly Plus 0-10V Dimmer. Wi-Fi Smart Dimmer Controller 0-10 VDC for all electrical installations

Shelly Plus 0-10V Dimmer. Wi-Fi Smart Dimmer Controller 0-10 VDC for all electrical installations

SKU:Plus 0-10V Dimmer

No reviews

Ask for Dealer Price

Regular price $14.90 USD
Regular price $14.90 USD Sale price $14.90 USD
Sale Sold out
Shipping calculated at checkout.
Retail: Get Free Shipping using code FREESHIP at checkout on orders from USD 75 (for US Continental, exclusions applies*).
Shipping to Canada? Write us for a customs estimation.

(*)See terms & conditions

Need more quantity? We have it! Contact us and we will get it for you

100% Secure Payments

The Shelly Plus 0-10V Dimmer is a Wi-Fi smart dimmer controller that is specifically designed for managing 0-10V dimming drivers. With precise dimming capabilities and remote control access, this dimmer is perfect for retrofit installation and is compatible with any regular switch in your household.

Use it with your existing switches!

Yes!! No need to invest in new, specialized dimmer switches that clash with your home's aesthetic. Now, even buttons that weren't originally designed for dimming can work with Shelly Plus 0-10V Dimmer. You can use your favorite style and brands of switches and seamlessly integrate dimming capabilities into your current setup.

Characteristics:

  • No hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Home Assistant, Hubitat or your preferred proprietary automation platform like Control4, Crestron, URC
  • Supports signal control for multiple types of drivers (lights, motors, valves, etc; depending on the driver)
  • One/dual button dimming mode (use with physical switches)
  • Wi-Fi Range Extender & BLE Gateway
  • Extremely fast processor for immediate reaction - ESP32
  • Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
  • Designed for installation in a limited space, such as wall mounts, electrical control panels, etc.
View full details

No hub required, Universally compatible

Shelly Products can be controlled locally, directly and without a hub through your smartphone/table with Shelly App - no hub or other equipment needed. Enable cloud feature and get remote control from anywhere. At the same time, you can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system.

Shelly App
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms Shelly compatible platforms

No hub required, Universally compatible

Shelly Products can be controlled locally, directly and without a hub through your smartphone/table with Shelly App - no hub or other equipment needed. Enable cloud feature and get remote control from anywhere. At the same time, you can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system.

Shelly App
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Shelly compatible platforms Shelly compatible platforms
Specifications

Physical
Size (HxWxD):42x37x17 ±0.5 mm / 1.65x1.46x0.66 ±0.02 in
Weight: 17 g / 0.60 oz
Screw terminals max torque:0.4 Nm / 3.5 lbin
Conductor cross section:0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules)
Conductor stripped length:5 to 6 mm / 0.20 to 0.24 in
Mounting:In-wall
Shell material:Plastic
Color:Shell: 2716C, print: black
Environmental
Ambient working temperature:-20 °C to 40 °C / -5 °F to 105 °F
Humidity30 % to 70 % RH
Max. altitude2000 m / 6562 ft
Electrical
Power supply:110 - 240 VAC ±10%
Power consumption: < 1.2 W
Neutral not needed:No
0-10 V Voltage control type:Sinking
Output circuits ratings
Max control voltage:10VDC
Max control current:0.35 W
Sensors, meters
Internal-temperature sensor:Yes
Radio
Wi-Fi
Wi-Fi protocol:802.11 b/g/n
Wi-Fi Range:Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
(Depends on local conditions)
Max. RF power:< 20 dBm
RF band:2401 - 2495 МHz
Bluetooth
Protocol:4.2
Range:Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
(Depends on local conditions)
Max. RF power:< 4 dBm
RF band:2400 - 2483.5 MHz
MCU
CPU:ESP32
Flash:4 MB
Firmware capabilities
Schedules:20
Webhooks (URL actions):20 with 5 URLs per hook
MQTT:Yes
Scripting:Yes

Collapsible content

Warranty

  • USA Pro Market Manufacturer Warranty: Lifetime manufacturer warranty (only if installed by a professional within USA)

  • Retail Standard Manufacturer Warranty (included in purchase price): 2 years manufacturer warranty covers only the hardware (corpus, mechanics, and display, if any) and does not cover consumables (battery) and accessories insofar as these are subject to exhaustion (decrease of their useful life) depending on the intensity of their use. Device malfunctions are only covered when device is used as described conditions within user manual (max loads, proper installation, etc.). Please check refund policy for further details.

Special Notes

  • Do It Yourself: Devices are technically user-installable in many locales, nevertheless consulting a licensed electrician to install shelly components is recommended; in addition to being licensed to work with electrical devices, they are also familiar with local building codes and regulations to keep your safety.
  • Manufacturer's Safety note: Each Shelly device generates heat under load. Do not combine two or more Shelly devices stacked on top of or beside each other in a confined space. There must be a minimum distance of 0.4 inch / 1 cm between them to allow for airflow.
