Shelly Wave 1 US LR UL. Z-Wave Long Range Smart Relay, 1-Channel 15A Dry Contact
Shelly Wave 1 US LR UL. Z-Wave Long Range Smart Relay, 1-Channel 15A Dry Contact
SKU:Wave 1 LR UL US
Ask for Dealer Price
Shipping to Canada or International? Take advantage of new flat rates.
(*)See terms & conditions
Need more quantity? We have it! Contact us and we will get it for you
Couldn't load pickup availability
Take smart control of your space with the Shelly Wave 1 US LR UL, a 1-channel dry contact smart relay designed for Z-Wave Long Range (ZWLR). With up to 1.5 miles of wireless communication range (line of sight), this device is perfect for large residential or commercial properties. Whether you're automating gates, garage doors, outdoor lighting, irrigation systems, or office equipment, this versatile relay delivers reliable performance with ultra-low power consumption.
Compatible with any Z-Wave gateway (required), it operates on 912 MHz (ZWLR) and 908.4 MHz (Z-Wave Plus), supporting scalable networks of up to 4,000 devices.
Key Features – Shelly Wave 1 US LR UL
- Z-Wave Long Range (ZWLR): Communicate over distances up to 1.5 miles line-of-sight, ideal for extended properties and detached buildings.
- 15A Dry Contact Relay: Supports a wide range of appliances and systems – from lighting and garage doors to pumps and irrigation.
- Smart Scene Capabilities: Trigger custom scenes such as turning on driveway lights when the gate opens or starting sprinklers at sunrise.
- Custom Schedules: Set up daily routines or sync with sunrise/sunset for seamless automation (Z-Wave gateway required).
- Low Power Operation: Designed for high performance with minimal energy usage.
- Secure and Scalable: Advanced encryption and support for large networks (up to 4,000 devices).
- 3-Year Manufacturer Warranty
Why Shelly Wave 1 US LR UL?
Designed as a retrofit-friendly solution, this relay offers powerful automation without rewiring. Whether you're upgrading an existing system or building a new one, Shelly Wave 1 US LR UL delivers long-range control, robust compatibility, and effortless integration into your smart ecosystem.
Shelly Wave works on Z-Wave
Z-wave features
-
Bulletproof security
Security 2 (AES128 encryption) for the utmost safety of your Z-Wave network
-
Ultra-low power consumption
Most of the Wave devices operate at less than 0.3W
-
High compatibility
Compatible with all certified Z-Wave devices and gateways available in the market
-
Extended wireless Long Range
Up to 80 m indoor range. Device acts as a Z-Wave signal repeater, extending
the Z-Wave network range -
High reliability
Operates on a sub-GHz frequency, ensuring stable and reliable wireless connection without interference
-
Automatic set-up
SmartStart for automatic inclusion to your Z-Wave network
Universally compatibleYou can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system. |
 |
||||
 |
 |
||||
 |
 |
||||
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
Universally compatibleYou can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Technical Specifications
| Power supply | 110–240 V AC / 24–48 V DC / 12 V DC ± 10% |
|---|---|
| Power consumption | < 0.3 W |
| Max. switched voltage (AC) | 240 V |
| Max. switched current (AC) | 15 A |
| Max. switched voltage (DC) | 30 V |
| Max. switched current (DC) | 10 A |
| Overheating protection | Yes |
| Long Range (depends on conditions) | Up to 80 m indoors / 1000 m outdoors |
| Z-Wave® repeater | No |
| Z-Wave® mesh range | Up to 40 m indoors; repeater: Yes |
| Z-Wave® frequency (LR) | 912 MHz |
| Z-Wave® frequency (mesh) | 908.4 MHz |
| CPU | Z-Wave® S800 |
| Size (H × W × D) | 37 × 42 × 16 ± 0.5 mm / 1.46 × 1.65 × 0.63 ± 0.02 in |
| Weight | 26 g / 0.92 oz |
| Mounting | In-wall box |
| Max. screw terminal torque | 0.4 Nm / 3.5 lbin |
| Conductor cross-section | 0.5 to 1.5 mm² / 20 to 16 AWG |
| Stripped conductor length | 5 to 6 mm / 0.20 to 0.24 in |
| Enclosure material | Plastic |
| Color | Blue |
| Ambient temperature | −20 °C to 40 °C / −5 °F to 105 °F |
| Humidity | 30% to 70% RH |
| Max. altitude | 2000 m / 6562 ft |
