Shelly Plus RGBW PM. Wi-Fi RGBW controller for LED strips. RGB+W, 4x single color LED strips or any LED dimmable lights (Open Box)
Shelly Plus RGBW PM. Wi-Fi RGBW controller for LED strips. RGB+W, 4x single color LED strips or any LED dimmable lights (Open Box)
SKU:Plus RGBW PM_OB_AN
Condition: Open Box
This product is sold AS IS, fully functional and inspected by Digital Bay Tech for proper operation and cosmetic condition, unless explicitly stated otherwise. Final sale, no returns or exchanges. Manufacturer warranty may apply if available. The customer is responsible for any shipping costs related to warranty service.(*)
Ask for Dealer Price
Precio habitual
$15.75 USD
Precio habitual
$31.49 USD
Precio de oferta
$15.75 USD
Precio unitario
por
Los gastos de envío se calculan en la pantalla de pago.
Shipping to Canada or International? Take advantage of new flat rates.
(*)See terms & conditions
Need more quantity? We have it! Contact us and we will get it for you
No se pudo cargar la disponibilidad de retiro
Experience effortless control of LED strips with the Shelly Plus RGBW PM. This compact and versatile controller supports RGBW, RGB, and Light profiles, allowing you to easily create the perfect ambiance for any occasion. Plus, with real-time power measurement, you can track energy consumption and ensure efficiency. Discover unparalleled flexibility and convenience with the Shelly Plus RGBW PM.
Shelly Plus RGBW PM allows you to manage RGB+W, 4x single color LED strips or any LED dimmable lights directly from your mobile device. Control 12-24 V DC, dim, power measure, and choose from a huge palette of RGB colors. Fast and easy to set up, it is designed to be easily fitted behind a built-in light switch, socket, junction, or electrical box.
Create unique ambiences in your home!! Make your LED lights smart in one easy step.
Shelly Plus RGBW PM - Main Features:
- Supports any 12V or 24VDC White (or color), RGB, RGBW LED strips
- Power measurement
- 3 lighting profiles for easy customization (four independent LED strips, RGB or RGBW)
- Adjustable transition duration & fade rate, as well as min/max brightness
- Independent control for RGB and White: Color brightness and white brightness now can be controlled independently with dimming up/down.
- Night mode
- Over-current protection
- Wi-Fi Range Extender & BLE Gateway
- Extremely fast processor for immediate reaction - ESP32
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
- No hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Home Assistant, or your preferred automation platform.
How to Install
How to Install
Funcionalidades
 |
 |
|
|
||
|
|
||
No se requiere un hub, universalmente compatibleLos productos de Shelly se pueden controlar localmente, directamente y sin hub a través de su teléfono inteligente/tableta con la aplicación Shelly, sin necesidad de un hub u otro equipo. Habilite la funcionalidad via nube y obtenga control remoto desde cualquier lugar. Al mismo tiempo, puede integrar directamente Shelly con prácticamente todos los hubs inteligentes, asistente de voz, plataforma de código abierto o sistema de control premium. |
 |
||||
 |
 |
||||
 |
 |
||||
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
No se requiere un hub, universalmente compatibleLos productos de Shelly se pueden controlar localmente, directamente y sin hub a través de su teléfono inteligente/tableta con la aplicación Shelly, sin necesidad de un hub u otro equipo. Habilite la funcionalidad via nube y obtenga control remoto desde cualquier lugar. Al mismo tiempo, puede integrar directamente Shelly con prácticamente todos los hubs inteligentes, asistente de voz, plataforma de código abierto o sistema de control premium. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Especificaciones
| Físico | |
|---|---|
| Tamaño (HxWxD): | 42x37x12 mm / 1.65x1.46x0.47 in |
| Peso: | 16 g / 0.56 oz |
| Torque máximo de terminales de tornillo: | 0.2 Nm / 1.8 lbin |
| Sección transversal del conductor: | 0.1 a 1 mm² / 30 a 16 AWG (sólido, trenzado y con terminales de punta) |
| Longitud del conductor pelado: | 6 mm / 0.24 in |
| Montaje: | En pared |
| Material de la carcasa: | Plástico |
| Color de la carcasa: | Amarillo |
| Color de los conectores: | Verde |
| Ambiental | |
| Temperatura de funcionamiento ambiental: | -20°C a 40°C / -5°F a 105°F |
| Humedad: | 30% a 70% RH |
| Eléctrico | |
| Fuente de alimentación: | 12/24 VDC |
| Consumo de energía: | < 1.2 W |
| Clasificaciones de los circuitos de salida | |
| Voltaje máximo de control: | 24 VDC |
| Corriente máxima de control: | 4 A por canal (10 A total) |
| Alcance: | Hasta 30 m / 98 ft en interiores y 50 m / 164 ft en exteriores (Depende de las condiciones locales) |
| Bluetooth | |
| Protocolo: | 4.2 |
| Banda RF: | 2400 - 2483.5 MHz |
| Potencia máxima de RF: | < 4 dBm |
| Alcance: | Hasta 10 m / 33 ft en interiores y 30 m / 98 ft en exteriores (Depende de las condiciones locales) |
| Unidad de microcontrolador | |
| CPU: | ESP32 |
| Frecuencia de reloj: | 160 Mhz |
| RAM: | 400 KB |
| Flash: | 4 MB |
| Capacidades del firmware | |
| Horarios: | 20 |
| Webhooks (acciones de URL): | 20 con 5 URL por hook |
| Script: | Sí |
| MQTT: | Sí |
